Multi function welding machne Tig ac dc SuperTIG250P pulse welder and plasma cutter, 220V aluminium inverter welding machine

Multi function welding machne Tig ac dc SuperTIG250P pulse welder and plasma cutter, 220V aluminium inverter welding machine

Model NO.: SUPER-TIG250P(Code.202194)
Delivery: FOB/EXW/FCA
Minimum order quantity: 3 pieces
Supply Ability: 2000 pieces / Week
Country of Origin: China
Stock Time: 5-15 Days

Inverter welding equipment for SUPER 250P at 40% duty cycle, designed for maximum quality industrial TIG and plasma cutter. Focused on INOX, aluminium, alloys and all kind of steel works.

Quantity:

Video Description

Specification

Model No	SUPER-250P(TIG-AC/DC-MMA-CUT)
Input (volts/amps)	220V 1 Phase AC 50/60Hz
MMA	No-load Voltage	65V
	Rated Output Current	20-250A
	Duty Cycle	25%
TIG	No-load Voltage	65V
	Rated Output Current	10-250A
	Duty Cycle	40%
	Up-Slope Time	0.1~10 Seconds
	Down-Slope Time	0.1-10 Seconds
	Pulse Current Range	10A ~ 250A
	Pulse Width Range	40%
	Pulse Frequency Range	0.5Hz ~ 100Hz
	Arc starting mode	HF Micro start
CUT	No-load Voltage	248V
	Rated Output Current	10-60A
	Duty Cycle	35%
	Arc starting mode	HF Micro start
Weight	25.6 KG
Insulation	IP21S
Dimensions	520275450mm

Product Description

TIG AC DC PULSE WELIDNG and Plasma CuttingMACHINE Super 200P ,excellent for aluminum welding ,also for metal cutting

1.This machine is great for AC/DC TIG, AC/DC Pulsed TIG, Plasma cutting, MMA / Suitable For Aluminum and Stainless Steel Welding /
Suitable for 6010 Electrode / IGBT Inverter
2. With big advantage of easy operation design,very convenience for fast operation.
3. Remote Control for Trigger / Foot-pedal optional.
4. Compact size only,net weight only,very easy to remove.
5.Great performance for aluminum welding.Please check the video

Packing & Delivery

Selling Units: Single item
Selling package size: 51X30X40 cm
Selling gross weight: 17.000 kg

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Certification：CE
Usage：TIG DC,TIG AC ,PULSE and MMA welding
Dimensions： 45X20X35CM
Power(W)：7000
Rated Current：200A
Input Voltage：220 V, One phase
Model Number：Super TIG200P
Brand Name：DANCY
Place of Origin：ZheJiang, China
Condition：New
TIG welder：Welding Process: TIG MMA CUT

This machine is 220V input,

It is great for AC/DC TIG, AC/DC Pulsed TIG, MMA and Air plasma cutter
Adopt IGBT inverter technology。
Suitable for aluminium and stainless stell welding/ Suitable for 6010 elecrtode/Suitable to cut carbon steel,stainless steel,all kinds of metal.

With big advantage of easy operation design ,one press and hold for 3 seconds the machine it enter to aluminum welding pre-setting,very convenience for fast operation.
Remote Control for Trigger / Foot-pedal optional.
Great performance for aluminum welding.
